class a motrohomes
1,200 Watts - $18,900.00
1,200 Watts - $18,900.00
1,200 Watts - $18,900.00
This is our basic Solar System Package designed for compact motorhomes with 50 amp single-phase and split-phase AC electric systems. This system will provide enough power to operate all 12 V DC RV and camper appliances and equipment. It will also supply sufficient 120 V AC power to operate multiple standard sized 120 V appliances at the same time, such as a microwave oven, water heater, TV or a coffee pot. One onboard air conditioning unit will be able to operate on battery power alone for 5-7 hours with this size solar system before the battery bank is depleted. Depending on solar panels output during daylight hours, air conditioning time will be able to be extended by an additional 4-6 hours.
Standard Equipment Included:
- (6) 200 Watt 12 Volt Monocrystalline Rigid Solar Panel by Renogy
- (1) Victron 150/70 MPPT Solar Charge Controller
- (8) 12 V 100 Ah or (4) 200 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy (800 Ah/9,600 Wh)
- (2) Victron Multiplus II GX 12/3,000 Hybrid Inverter Charger connected in parallel for split phase 50 amp travel trailers
- (1) Victron Touch 70: touch screen remote/display for controlling and monitoring
- (1) Cerbo GX Networking Hub: allows remote monitoring via Bluetooth and internet
- (1) Victron Smart Shunt Battery Monitor
- All wire, fuses, bus-bars, disconnect switches, sealant, hardware, etc. as needed for a typical installation*
- All labor for a typical installation*
1,600 Watts - $20,900.00
1,200 Watts - $18,900.00
1,200 Watts - $18,900.00
This our standard Solar System Package designed for standard size motorhome with 50 amp single-phase and split-phase AC electric systems. This system will provide enough power to operate all 12 V DC RV and camper appliances and equipment. It will also supply sufficient 120 V AC power to operate multiple standard sized 120 V appliances at the same time, such as a microwave oven, water heater, TV or a coffee pot. One onboard air conditioning unit will be able to operate on battery power alone for 6-8 hours with this size solar system before the battery bank is depleted. Depending on solar panels output during daylight hours, air conditioning time will be able to be extended by an additional 6-8 hours.
Standard Equipment Included:
- (8) 200 Watt 12 Volt Monocrystalline Rigid Solar Panel by Renogy
- (2) Victron 150/35 MPPT Solar Charge Controller
- (4) 12 V 200 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy (800 Ah @ 12 V/9,600 Wh)
- (2) Hybrid Inverter Victron Multiplus II12/3,000 Hybrid Inverter Charger for 50 amp RV’s
- (2) Orion-Tr 12/12 (360 W) Smart DC-DC Charger isolated by Victron
- (1) Victron Touch 70: touch screen remote/display for controlling and monitoring
- (1) Cerbo GX Networking Hub: allows remote monitoring via Bluetooth and internet
- (1) Victron Smart Shunt Battery Monitor
- All wire, fuses, bus-bars, disconnect switches, sealant, hardware, etc. as needed for a typical installation*
- All labor for a typical installation*
2,000 Watts - $24,900.00
1,200 Watts - $18,900.00
2,000 Watts - $24,900.00
This our Premier Solar System Packages designed for large size motorhomes with 50 amp single-phase and split-phase AC electric systems. This system will provide enough power to operate all 12 V DC RV and camper appliances and equipment. It will also supply sufficient 120 V AC power to operate multiple standard sized 120 V appliances at the same time, such as a microwave oven, water heater, TV or a coffee pot. One onboard air conditioning unit will be able to operate on battery power alone for 8-10 hours with this size solar system before the battery bank is depleted. Depending on solar panels output during daylight hours, air conditioning time will be able to be extended by an additional 8-6 hours.
Standard Equipment Included:
- (10) 200 Watt 12 Volt Monocrystalline Rigid Solar Panel by Renogy
- (2) Victron 150/35 MPPT Solar Charge Controller
- (6) 12 V 200 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy (1,200 Ah @ 12 V/14,400 Wh)
- (2) Hybrid Inverter Victron Multiplus II12/3,000 Hybrid Inverter Charger for 50 amp RV’s
- (2) Orion-Tr 12/12 (360 W) Smart DC-DC Charger isolated by Victron
- (1) Victron Touch 70: touch screen remote/display for controlling and monitoring
- (1) Cerbo GX Networking Hub: allows remote monitoring via Bluetooth and internet
- (1) Victron Smart Shunt Battery Monitor
- All wire, fuses, bus-bars, disconnect switches, sealant, hardware, etc. as needed for a typical installation*
- All labor for a typical installation*
AVAILABLE OPTIONS
- (1) 100 Watt 12 Volt Monocrystalline Rigid Solar Panel by Renogy - $290.00 including installation.
- (1) 200 Watt 12 Volt Monocrystalline Rigid Solar Panel by Renogy - $490.00 including installation.
- (1) 12 V 100 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy - $600.00 including installation.
- (1) 12 V 200 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy - $1,200.00 including installation.
- (1) Micro-Air Easy Start: $790.00 per A/C including installation.
- Upgrade to 12 V 100 Ah Lithium Iron Phosphate Smart Battery by Battle Born Batteries- $1,150.00 per (1) battery including installation.
- Upgrade to Heated 12 V 100 Ah Lithium Iron Phosphate Smart Battery by Battle Born Batteries- $1,300.00 per (1) battery including installation.
*50% of package price is due upon scheduling the installation.
*Prices subject to product availability and market cost fluctuation.
*Prices do not include Sales Tax.
*$200.00 per day fee will be applied to all mobile installations.
