Fifth Wheel Travel trailers

This is our basic Solar System Package designed for compact size fifth wheel campers with 30 amp single-phase AC electric systems.  This system will provide enough power to operate all 12 V DC RV and camper appliances and equipment. It will also supply sufficient 120 V AC power to operate one standard size 120 V appliance at a time, such as a microwave oven, water heater or a coffee pot.  One onboard air conditioning unit will be able to operate on battery power alone for 4-6 hours with this size solar system before battery bank is depleted. Depending on solar panels output during daylight hours, air conditioning time will be able to be extended by additional 3-5 hours.

Standard Equipment Included:

• (10)  100 Watt 12 Volt Monocrystalline Solar Panel by Renogy
• (1)  Rover Li 60 Amp MPPT Solar Charge Controller by Renogy
• (6)  12V 100Ah  or (3) 200Ah  Lithium Iron Phosphate Battery w/ Bluetooth by Renogy  (600Ah/7,200 Wh)
• (1)   3000W 12V Pure Sine Wave Inverter Charger w/ LCD Display by Renogy
• (1) Communication Hub with BT-2 Bluetooth Module by Renogy
•   Renogy ONE M1 system monitoring display
•  All wire, fuses, bus-bars, disconnect switches, sealant, hardware, etc. as needed for a typical installation*
• All labor for a typical installation*

 This our standard Solar System Packages designed for standard  size fifth wheel campers with 50 amp single-phase and split-phase AC electric systems.  This system will provide enough power to operate all 12 V DC RV and camper appliances and equipment. It will also supply sufficient 120 V AC power to operate multiple standard sized 120 V appliances at the same time, such as a microwave oven, water heater, TV or a coffee pot.  One onboard air conditioning unit will be able to operate on battery power alone for 6-8 hours with this size solar system before the battery bank is depleted. Depending on solar panels output during daylight hours, air conditioning time will be able to be extended by an additional 4-6 hours.

Standard Equipment Included:

• (7) 200 Watt 12 Volt  Monocrystalline Rigid Solar Panel by Renogy
• (2)  Victron 150/35 MPPT Solar Charge Controller
• (4)  12 V 200 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy (800 Ah @ 12 V/9,600 Wh)
• (2) Hybrid Inverter Victron Multiplus II12/3,000 Hybrid Inverter Charger for 50 amp RV’s
• (2)   Orion-Tr 12/12 (360 W)  Smart DC-DC Charger isolated by Victron
• (1)  Victron Touch 70: touch screen remote/display for controlling and monitoring
• (1)  Cerbo GX Networking Hub: allows remote monitoring via Bluetooth and internet
• (1)  Victron Smart Shunt Battery Monitor
• All wire, fuses, bus-bars, disconnect switches, sealant, hardware, etc. as needed for a typical installation*
• All labor for a typical installation*

This our premium Solar System Packages designed for large size fifth wheel campers with 50 amp single-phase and split-phase AC electric systems.  This system will provide enough power to operate all 12 V DC RV and camper appliances and equipment. It will also supply sufficient 120 V AC power to operate multiple standard sized 120 V appliances at the same time, such as a microwave oven, water heater, TV or a coffee pot.  One onboard air conditioning unit will be able to operate on battery power alone for 8-10 hours with this size solar system before the battery bank is depleted. Depending on solar panels output during daylight hours, air conditioning time will be able to be extended by an additional 5-7 hours.

Standard Equipment Included:

• (9) 200 Watt 12 Volt  Monocrystalline Rigid Solar Panel by Renogy
• (2)  Victron 150/35 MPPT Solar Charge Controller
• (6)  12 V 200 Ah Lithium Iron Phosphate Battery w/ Bluetooth by Renogy (1,200 Ah @ 12 V/14,400 Wh)
• (2) Hybrid Inverter Victron Multiplus II12/3,000 Hybrid Inverter Charger for 50 amp RV’s
• (2)   Orion-Tr 12/12 (360 W)  Smart DC-DC Charger isolated by Victron
• (1)  Victron Touch 70: touch screen remote/display for controlling and monitoring
• (1)  Cerbo GX Networking Hub: allows remote monitoring via Bluetooth and internet
• (1)  Victron Smart Shunt Battery Monitor
• All wire, fuses, bus-bars, disconnect switches, sealant, hardware, etc. as needed for a typical installation*
• All labor for a typical installation*
